Safety Speed 6480-20C Vertical Panel Saw

Description

The 6480-20C is a compact panel saw with a 5’ frame, and a 50” maximum crosscut with a 96” rip cut capacity. Featuring a cut accuracy of 1/32″, and a 1.75″ cut depth, the 6480-20C is eerily similar to Safety Speed’s flagship C4 panel saw while having optional accessories built into the price.



These include a folding stand and wheels allowing you to move your 6480-20C around your shop, as well as well as a general-purpose blade, and a dust bonnet. The dust bonnet allows you to connect your machine to a dust collection kit and vacuum.



Wheels and a folding stand provide portability for your compact panel saw and allow you to move it around your shop as you see fit.



Standard Equipment

• 3 ¼ Hp, 15 amp industrial, Milwaukee Tool motor
• Folding Stand
• Wheels
• Zinc plated 1 ¾” steel guide tubes
• 4 Nylatron roller bearing systems
• Adjustable vertical and horizontal rulers
• Quick change from vertical to horizontal cutting
• Thin material pressure guard
• Injection-molded plastic material rollers
• Spring loaded counter balance system
• Integrated dust collection bonnet
• Extended warranty
• TUV certified to UL/CSA standards



Specifications:

• Weight 189 lbs
• Dimensions 60 x 11 x 70in
• Max. Crosscut 50″/1270mm
• Max. Rip Cut 96″/2450mm
• Cut Depth 1 ¾”/45mm
• Cut Accuracy 1/32″/.8mm
• Frame Length 60″/ 525mm
• Saw Blade Diameter 8″/210mm
• Saw Blade Bore Size 5/8″
• Daily Usage 1-3 Hours
• Rollers 8
• Motor volt and amperage 15 amp, 120V, 7.5 amps, 220V
• Motor Manufacturer Milwaukee Tool
• Machine Footprint 15sqft
• Machine Length 60″/1525mm
• Machine Height 75″/1900mm
• Machine Width with stand attached 36″/915mm
• Circular Saw Motor Revolutions Per Minute (RPM) 5,800 RPM
• Country of Origin USA
